Description:

Straight copper tube is a kind of mature copper tube&pipe in the market which had been applied to lots of different field, such as air conditioning,refrigeration,heat exchanger,distribution,connecting tube,fire protection,solar,gas and water transmission,plumbing and so on.

Straight copper tube for HVAC&R industry,Straight copper tubing for water PLUMBING .etc

Main material: 99.99% copper

General size:

1)Grade : C12200,C1220, CU-DHP,C11000

2)Outside Diameter: 4mm-152mm

3) Wall Thickness: 0.3mm-5mm

4)Length: 3m 5.8m 6m etc

Production Standard: ASTM B280 EN12735-1 AS/NZS 1571 JISH3300,AS1432

Copper tube Temper: hard ,half hard, soft

Package: Each end capped ,bundled by the foam bags and then put into the caontainer or wooden BOX.

Product code and size:

Straight copper water tube (AS1432)

Main material: 99.99% copper

General size:

1)Grade : C12200,

2)Outside Diameter: 4mm-152mm

3) Wall Thickness: 0.5mm-5mm

4)Length: 3m 5.8m 6m etc

Production Standard: AS1432.

Copper tube Temper: hard ,half hard,

Package: Each end capped ,bundled by the foam bags and then put into the caontainer or wooden BOX.

Product code and size:

Straight copper water tube,EN1057

Main material: 99.99% copper

General size:

1)Grade : CU-DHP

2)Outside Diameter: 6mm-160mm

3) Wall Thickness: 0.5mm-5mm

4)Length: 3m 5.8m 6m etc

Production Standard: EN 1057

Copper tube Temper: hard ,half hard,

Package: Each end capped ,bundled by the foam bags and then put into the caontainer or wooden BOX.

Product code and size:

Straight copper water tube,ASTM B88

Main material: 99.99% copper

General size:

1)Grade : C1100,C1020, C1220, CU-DHP

2)Outside Diameter: 4mm-105mm

3) Wall Thickness: 0.5mm-5mm

4)Length: 3m 5.8m 6m etc

Production Standard: ASTM B88

Copper tube Temper: hard ,half hard,

Package: Each end capped ,bundled by the foam bags and then put into the caontainer or wooden BOX.

Product code and size:
