Rolled Products
ZZL is your source for a very large range of brass, phosphor bronze, and copper rolled products with extremely fast deliveries and very competitive pricing! Our mill can offer coinage quality material for minting applications, and high-quality strip for defense and automotive applications. We also can provide bullet jacket cups and cartridge case cups for all standard calibers in large volumes.
Some of the Industries Served:
Automotive
Defense/ammunition
Antimicrobial
Building and Construction
Coinage
Electrical
Data and Communications
The products are mainly used in nuclear power, hydropower, shipbuilding, metallurgy, chemical industry and other fields. Product availability: 0.3-150mm thick; Width: 200-3100mm; Length ≤ 8000mm.
GRADE | TECHNOLOGY | TEMPER | SPECIFICATION(MM) |
|
THICKNESS | WIDTH | LENGTH |
|
|
COPPER & BRASS & BRONZE | HOT ROLLED | M20 | 4~8 | 600~3100 | ≤6000 |
|
＞8~150 | 200~3100 | ≤6000 |
|
COLD ROLLED | O60、H01、H02、H04、H06、H08 | 0.3~＜0.5 | 400~610 | ≤2000 |
|
0.5~3.0 | 400~1020 | ≤3000 |
|
＞3.0~12 | 400~3100 | ≤8000 |
|
COPPER ALLOYS
UNS (USA) | ASTM | EN Symbol | EN No | BS (UK) | JIS (Japan) |
C10200 | B-152 | Cu-OF | CW008A | C103 | C10120 |
C10300 | B-152 | Cu-PHC, SE-Cu | CW020A | - | - |
C11000 | B-152 | Cu-ETP | CW004A | C101 | C11000 |
C12200 | B-152 | Cu-DHP, SF-Cu | CW024A | C106 | C12200 |
C14410 | B-152 | CuSn0,15 | CW117C | - | - |
C19400 | B465, B888 | Cu-Fe2P | CW107C | - | - |
Chemical Composition
Alloy | Cu | Sn | P | Ag | O |
C10200 | 99.95 | - | - | - | 0.0010 |
C10300 | 99.99 | - | 0.001-0.006 | - | - |
C11000 | 99.90 | - | - | 0.0025 | 0.040 |
C12200 | 99.90 | - | 0.015-0.040 | 0.0025 | - |
C14410 | 99.90 | 0.15 | 0.006 | - | - |
C19400 | 97.00 | - | 0.015-0-.15 | - | - |
General Characteristics | Applications |
- Good Electrical and Thermal Conductivity
- Good Electroplating Ability
- Good Corrosion Resistance
- Good Cold Forming and Deep Drawing Qualities
- Perfect Soldering and Welding
- Excellent Against Stress Corrosion Cracking
| - Electric and Electronic Industry
- Automotive Industry
- Construction Industry
- Circuit Breakers
- Contact Springs
- Lead Frames
- Roofing
- E.V. Components
- Jewelry
|
Available sizes and specifications |
Copper & Brass & Bronze Plate & Sheet | Thickness: 0.3mm - 150.0mm Width:200mm - 3100mm Length:≤8100mm |
Copper &Brass & Bronze Coil & Strip & Foil | Thickness: 0.045mm - 3.0mm Width: 1mm - 1220mm |
Copper &Brass & Bronze Pipe & Tube | Outside diameter: 0.8mm - 368mm Thickness: 0.1mm -65mm |
Copper &Brass & Bronze Bar & Rod | Diameter: 1-300mm |
Copper &Brass & Bronze Wire | Diameter: 0.01-10mm |
