Stainless steel is a corrosion-resistant alloy of iron, chromium and, in some cases, nickel and other metals.
Completely and infinitely recyclable, stainless steel is the “green material” par excellence. In fact, within the construction sector, its actual recovery rate is close to 100%. Stainless steel is also environmentally neutral and inert, and its longevity ensures it meets the needs of sustainable construction. Furthermore, it does not leach compounds that could modify its composition when in contact with elements like water.
In addition to these environmental benefits, stainless steel is also aesthetically appealing, extremely hygienic, easy to maintain, highly durable and offers a wide variety of aspects. As a result, stainless steel can be found in many everyday objects. It also plays a prominent role in an array of industries, including energy, transportation, building, research, medicine, food and logistics.
ZLYS provides a wide range of welded and seamless stainless steel pipe to meet your application requirements.
We also offer rectangular steel tubing, square tubing, and round tubing in stainless steel and other materials.
Request a quote for your steel pipes today.
Stainless Steel Pipe/Tube Specifications
| Pipe | Specifications |
| Pipe Types | Seamless Pipe, ERW Pipe, Welded Pipe, Fabricated Pipe, LSAW Pipe, Box Pipe. |
| Schedule | SCH5, SCH10, SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120,SCH140, SCH160, XXS |
| Standard | ASME/ANSI B16.11, MSS-SP-97, MSS-SP-79, JIS B2316, BS 3799 |
| Pipe Size | 1/8″NB to 24″NB & 1/4″OD TO 24″OD AND 6.35mm to 254mm OD Thickness: 0.6mm to 20mm |
| Grades |
| Stainless Steel | ASTM /ASME A/SA 213 / 249 / 269 / 312 / 358 CL. I to V – 304 , 304L , 304H, 309S ,309H , 310S, 310H , 316 , 316TI , 316H , 316 LN , 317 , 317L , 321 , 321H , 347 , 347 H , 904L . |
Stainless Steel Pipe Chemical Composition
| Type | C | Mn | P | S | Si | Cr | Ni | Mo |
| 302 | 0.15 | 2.00 | 0.045 | 0.030 | 1.00 | 17.00/19.00 | 8.00/10.00 | - |
| 304* | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 18.00/20.00 | 8.00/10.50 | - |
| 304L* | 0.03 | 2.00 | 0.045 | 0.030 | 1.00 | 18.00/20.00 | 8.00/12.00 | - |
| 309 | 0.20 | 2.00 | 0.045 | 0.030 | 1.00 | 22.00/24.00 | 12.00/15.00 | - |
| 309S | 0.08 | 2.00 | 0.045 | - | 1.00 | 22.00/24.00 | - | - |
| 310 | 0.25 | 2.00 | 0.045 | 0.030 | 1.5 | 24.00/26.00 | 19.00/22.00 | - |
| 310S | 0.08 | 2.00 | 0.045 | 0.030 | 1.5 | 24.00/26.00 | 19.00/22.00 | - |
| 316* | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 16.00/18.00 | 10.00/14.00 | 2.00/3.00 |
| 316L* | 0.03 | 2.00 | 0.045 | 0.030 | 1.00 | 16.00/18.00 | 10.00/14.00 | 2.00/3.00 |
| 317 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00/1.00 | 18.00/20.00 | 11.00/15.00 | 3.00/4.00 |
| 317L | 0.03 | 2.00 | 0.045 | 0.030 | 0.75 | 18.00/20.00 | 11.00/15.00 | 3.00/4.00 |
| 321 | 0.08 | 2.00 | 0.040 | 0.030 | 1.00 | 17.00/19.00 | 9.00/12.00 | 0.75/0.75 |
| 347 | 0.08 | 2.00 | 0.040 | 0.030 | 0.5/1.00 | 17.00/19.00 | 9.00/12.00 | 0.5/0.75 |
| 410* | 0.15 | 1.00 | 0.040 | 0.030 | 1.00 | 11.5 / 13.5 | - | - |
| 410S | 0.08 | 0.30/0.65 | 0.030 | 0.010 | 0.15/0.50 | 12.00 / 12.60 | 0.20/0.55 | 0.20/0.55 |
| 416 | 0.15 | 1.25 | 0.060 | 0.15 min | 1.00 | 12.00 / 14.00 | - | - |
| 420 | 0.15 min | 1.00 | 0.040 | 0.030 | 1.00 | 12.00 / 14.00 | - | - |
| 430 | 0.15 | 1.00 | 0.040 | 0.030 | 1.00 | 16.00 / 18.00 | - | - |
| 440C | 0.95/1.20 | 1.00 | 0.040 | 0.030 | 1.00 | 16.00 / 18.00 | - | 0.75 |
Applications for stainless steel pipe include:
Food processing
Textile operations
Breweries
Water treatment plants
Oil and gas processing
Fertilizers and pesticides
Chemical applications
Construction
Pharmaceuticals
Automotive components
We provide stainless pipe in a range of sizes to meet your application requirements.
Contact us today for more information or request a quote for stainless steel piping.
Mechanical Properties
| Type | UNS | Tensile(ksi) min | Yield(ksi) min | Elongationmin | Hardness(Brinell) max | Hardness(Rockwell B) max |
| 302 | S30200 | 75 | 30 | 40% in 2" | 183 | 88 |
| 304* | S30400 | 75 | 30 | 40% in 2" | 183 | 88 |
| 304L* | S30403 | 70 | 30 | 40% in 2" | 183 | 88 |
| 309 | S30900 | 75 | 30 | 40% in 2" | 217 | 95 |
| 309S | S30908 | 75 | 30 | 40% in 2" | 217 | 95 |
| 310 | S31000 | 75 | 30 | 40% in 2" | 217 | 95 |
| 310S | S31008 | 75 | 30 | 40% in 2" | 217 | 95 |
| 316* | S31600 | 75 | 30 | 40% in 2" | 217 | 95 |
| 316L* | S31603 | 70 | 25 | 35% in 2" | 217 | 95 |
| 317 | S31700 | 75 | 30 | 35% in 2" | 217 | 95 |
| 317L | S31703 | 75 | 30 | 35% in 2" | 217 | 95 |
| 321 | S32100 | 75 | 30 | 40% in 2" | 183 | 88 |
| 347 | S34700 | 75 | 30 | 40% in 2" | 183 | 88 |
| 410* | S41000 | 65 | 30 | 20% in 2" | 217 | 95 |
| 410S | S41008 | 60 | 30 | 22% in 2" | 183 | 88 |
| 416 | S41600 | 75 | 40 | 30-25% in 2" | - | 82 |
| 420 | S42000 | 95 | 60 | 30-25% in 2" | - | 92 |
| 430 | S43000 | 65 | 30 | 22% in 2" | 183 | 88 |
| 440C | S44004 | - | - | - | - | - |
Request a quote for your steel pipes today.
